Optimized Imaging Experience
DirectClear Technology is a novel, patent-pending process that elevates transducer performance:
- Improved penetration and contrast resolution: Unlike conventional SonoSite transducers, a more efficient material has been embedded into the design that allows for the generation of more acoustic signal. In parallel, a reflective layer has been added to reduce the loss of this signal, as it is transmitted into the patient.
- Sharpened detail resolution: An additional layer has been added to provide a better acoustic match between the transducer and the patient, increasing the ability to resolve small structures and aid in your diagnostic confidence.
Intelligence, Inspired By You
- Touchscreen menu automatically adapts to your needs
- Tactile knobs for gain and depth control
- Virtual track pad displays only when needed
- Flexible control of caliper, zoom, and color box through virtual track pad or touchscreen
- Easy access to commonly used controls (Mode, Print, Save)
- Embedded Dual Transducer Connector: Switch exam types or transducers with two taps on the screen
Workflow Extended, From System To Stand
- Lockable drawer with tray behind system
- Dedicated gel bottle holder
- Elevated transducer holders
- Large storage basket
Highlighted Features:
- 180 degree screen rotation
- Dual battery design
- Ergonomic control panel
- Ultra-portable design
Sonosite SII Transducers
L38xi
10-5 MHz Linear
Applications: lung, nerve, small parts, arterial, venous
Scan depth: 9 cm
HFL38xi
13-6 MHz Linear
Applications: breast, lung, musculoskeletal, nerve, ophthalmic, small parts, arterial, venous
Scan depth: 6 cm
HFL50x
15-6 MHz Linear
Applications: breast, musculoskeletal, nerve, small parts
Scan depth: 6 cm
L25x
13-6 MHz Linear
Applications: lung, musculoskeletal, nerve, superficial, arterial, venous, ophthalmic
Scan depth: 6 cm
C11x
8-5 MHz Curved
Applications: abdominal, neonatal, nerve, venous, arterial, cardiology (vet)
Scan depth: 13.5 cm
rC60xi
5-2 MHz Curved
Applications: abdominal, musculoskeletal, nerve, ob, gyn
Scan depth: 30 cm
ICTx
8-5 MHz Curved
Applications: ob, gyn
Scan depth: 13 cm
rP19x
5-1 MHz Phased
Applications: abdominal, cardiology, lung, ob
Scan depth: 35 cm
P10x
8-4 MHz Phased
Applications: ped. abdominal, ped. cardiology, neonatal head
Scan depth: 14 cm
HSL25x
13-6 MHz Linear
Applications: lung, musculoskeletal, nerve, superficial, arterial, venous, ophthalmic
Scan depth: 6 cm
L52x (Vet)
10-5 MHz Linear
Applications: musculoskeletal, ob, arterial
Scan depth: 15 cm
C35x
8-3 MHz Curved
Applications: abdominal, musculoskeletal, nerve, ob, spine
Scan depth: 15 cm
C8x8-5 MHz Curved
Applications: prostate
Scan depth: 11.5 cm
